| 2.0寸 480*360 | 分辨率 | Resolution | 480x360 |
| 支持接口 | Interface Type | MIPI | |
| 显示区尺寸 | Display area | 40.82x30.62(mm) | |
| LCM外形尺寸 | LCM Dimensions | 43.95x38.8x2.06(mm) | |
| 显示点间距 | Dot Pitch | 0.0021 * 0.0850(mm) | |
| 显示色彩 | color | 16.7M | |
| 对比度 | Contrast Ratio | 800：1000 | |
| 响应时间 | Response time | 45ms | |
| 模组亮度 | Brightness | 820cd/㎡ | |
| 产品类型 | product type | TFT | |
| 显示类型 | Display Type | Normal Black | |
| 视角 | View Angle | 全视角 | |
| 工作温度 | Operating temperature | -20℃~+70℃ | |
| 储存温度 | Storage temperature | -30℃~+80℃ | |
| 是否支持定制 | Customisation | Yes |
