| 4.7寸 INCELL液晶显示屏 | 分辨率 | Resolution | 720*1600 |
| 支持接口 | Support Interface | MIPI | |
| 显示区尺寸 | Display Area | 48.99*108.86(mm) | |
| LCM外形尺寸 | Dimensions | 51.19*113.96*1.52(mm) | |
| 显示点间距 | Dot Pitch | 68.04um*68.04um | |
| 显示色彩 | Color | 16.7M | |
| 对比度 | Contrast Ratio | 1000:1500 | |
| 响应时间 | Response Time | 35ms | |
| 亮度 | Brightness | 500cd/m²（MIN） | |
| 触摸类型 | Touch Type | INCELL | |
| 显示类型 | Display Type | Normal Black | |
| 视角 | View Angle | U/D/L/R: 80/80/80/80 | |
| 工作温度 | Operating Temperature | -20℃~+70℃ | |
| 储存温度 | Storage Temperature | -30℃~+80℃ | |
| 是否支持定制 | Customisation | Yes |
